20 Ton Ram Splitter Horizontal Gas Log Splitter (H20-2)

Product Description
Limited Time Free Shipping!
This H20-2 Ram Splitter Horizontal 20 ton wood splitter is built tough to withstand many types and sizes of logs for your personal use. This log splitter is a competitive priced unit with imports, but you get a made in USA splitter and don’t give up on quality and durability.
This log splitter is powered by a horizontal shafted Subaru SP170 6HP motor that has a cast-iron cylinder liner. You will not find that on any low end motor. Combined with a 3 year residential warranty this motor is hard to beat.
This log splitter is customizable with the following options:
4 Way Wedge – Split logs into 4 pieces. 4 way wedge just slips over existing single wedge. (Can slide on and off quickly, choose 4 way wedge option to see picture) 4 way wedge will reduce opening size by 2″.
Log Cradles – Horizontal units will hold logs in place to prevent from having to hold log with hand.
See options above the big green “add to cart” button for pricing and pictures. As you select them it will built and price your splitter as you go! Questions? Feel free to contact us at 888-706-2434 for no hassle no pressure help and advice. We are here to help. Please note images may slightly differ from actual item.
Please note these log splitters are delivered via freight truck. You will be responsible to take the crate off the back of the truck unless you select lift gate delivery as an option. Some assembly is required.
Detailed Specifications
Beam Structure:
2″ wide x 5″ tall – 5″ Top Plate Tubular Design
Splitting Wedge:
8″ High
Operating Position:
Horizontal
Force / Tonnage:
20 Ton (40,000 lbs)
Cylinder :
4″ x 24″ 1.5″ rod
Cycle Time:
13-15 Seconds (Approx)
Log Opening :
26 Inches
Wheels & Tires:
High-Speed, 4.80 x 8
Road Towable:
Yes – 2″ Coupler & Safety Chains
Engine:
5.7 HP Subaru SP-170
Working Height:
19 Inches
Operating Size:
50″ wide and 84″ long
Hydraulic System:
5 Gallon Tank + Cylinder, and Hoses
Safety Control Valve:
Detent, Auto Return
2 Stage Pump:
11 Gallons Per Minute
Operation Weight :
485 LBS
Warranty:
1 Year / 3 Year Motor (Residential)
Made in USA:
Yes!
4 Way Wedge:
Optional
