Simplicity Broadmoor Tractor 25 HP Briggs Professional 52″ FAB Deck Suspension #2691674

BROADMOOR™ LAWN TRACTOR
Bring Comfort and Performance to Your Lawn
Can a lawn tractor be both high-performing and comfortable? The Simplicity Broadmoor™ answers this question with a definite “YES”! With the unique Free Floating™ Mower Deck, rear suspension and breathable ergonomic mesh tractor seat, mowing the lawn will never feel like yard work.

Model Number
2691674

Marketing Model
25/52″ SCS

Start Type
Electric, Push Button

Power Rating *
25

Cylinders
2

Engine Displacement (cc)
724

Choke/Throttle
Ready Start®, Single-Lever

Fuel Tank Capacity (gal)
3.6

Battery (cca)
230

Transmission Type
Tuff Torq® K62

Transmission Differential
Hydrostatic

Ground Speed-Fwd (mph)
0-6.7

Ground Speed-Rev (mph)
0-4.0

Automatic Controlled Traction™
Standard

4-Wheel Drive
N/A

Brake
Disc

Frame Steel
10-Gauge

Front Axle
Cast-Iron

Front Tires (in)
16 x 6.5 – 8 /Turf

Rear Tires (in)
23 x 10.5 – 12 /Turf

Attachment Lift
Integrated Hydraulic Dash Lever

Seat
High-Back Mesh

Suspension
SCS, Rear

Mower Deck Type
Fabricated Free Floating™

Cutting Width (in)
52

Number of Blades
3

Height-of-Cut (in)
1.25 – 4.5

Height-of-Cut Positions
Infinite/Electric

Blade Engagement
Electric PTO Switch

Rear Rollers
Standard, Full-Width Striping

Mower Deck Removal
Integrated Hydraulic Dash Lever

Spindle
Commercial Aluminum w/ Zerk Fittings

Mower Steel Gauge
10-Gauge

Washout Port
Standard

Cruise Control
Standard

Steering
Power Steering

Headlights
Standard, LED

Hour Meter
Standard

Fuel Level Indicator
Digital, Dash

12 Volt DC Outlet
Yes

Hand Grips
Standard

Deluxe Instrumental Panel
N/A

Cup Holder
Standard

Turning Radius (in)
18

Assembled Length (in)
76

Assembled Width (in)
63

Assembled Height (in)
48

Consumer Warranty (Product) **
3-Years

Commercial Warranty (Product) **
90-Days

Fabricated Mower Deck Warranty **
Lifetime
